If you own a GE Profile Combo Unit Double Oven, such as the GE PT7050EH1ES, GE PT7550SF1SS, or another model, you may have encountered the frustrating F34 or F35 error codes. These error codes often appear after a power surge or spike, causing the oven to beep incessantly, display the error code, and prevent you from using the oven. But don’t worry! In this guide, we’ll walk you through how to fix the F34 or F35 error codes on your GE Profile double oven.
What Does F34 and F35 Mean on GE Profile ? 🤔
The F34 and F35 error codes on your GE Profile double oven typically indicate a problem with the relay boards that control the upper and lower elements of your oven.
- F34 is usually associated with the upper relay board (located on the left side behind the control panel).
- F35 is typically linked to the lower relay board (located behind the control panel as well).
These errors are often caused by power surges or power spikes, which can disrupt the functionality of these boards, rendering your oven unusable.
A Rare Occurrence: Temperature Sensors and Cooling Fan on GE Profile
Although it’s relatively rare, the F34 and F35 error codes can also be triggered by issues with the temperature sensors or the cooling fan in your GE Profile oven. If the sensors aren’t properly reading temperatures or the cooling fan isn’t functioning, it could cause the oven to fail in the same way that a relay board malfunction would.
How to Fix F34 or F35 Error Code on Your GE Profile Combo Oven 🔧
Before attempting any repair, ensure the oven is unplugged to avoid electrical shock or injury. Always proceed with caution when working with electrical components.
- Power Cycle the Oven 🔌
Sometimes, the issue can be resolved by simply resetting the oven. Start by pressing the light button or turning the power on/off to see if the error code clears. This simple step often fixes minor glitches caused by power surges. - Access the Control Panel
If the error persists, you’ll need to access the relay boards behind the control panel. Here’s how you can do it:- Remove Two Screws: First, remove the two screws located under the control panel (the touchpad). This will allow you to slightly lift the panel to access the internal components.
- Lift the Control Panel: Gently lift the control panel to expose the relay boards behind it. You may need to apply a little pressure, but be careful not to damage the panel.
- Unplug the Control Panel Cable 🔌
Once the control panel is lifted, you’ll notice a cable that connects the control panel to the oven’s main system. Unplug this cable carefully to avoid damaging the connectors. - Identify the Relay Boards ⚡
Behind the control panel, you should see a metal bracket secured by four screws. Remove these screws to detach the metal bracket. Once the bracket is removed, you’ll have access to both the upper relay board (for F34) and lower relay board (for F35). - Take a Picture for Reference 📸
Before you unplug any wires from the relay boards, take a clear picture of the wiring setup. This will help you correctly reconnect the wires later on. - Replace the Faulty Relay Board(s) ⚡
If you can visually identify any damaged components, such as burn marks or scorch damage, you’ll need to replace the corresponding relay board. The F34 error typically indicates an issue with the upper relay board, while F35 points to the lower relay board.Order the correct replacement parts from a trusted supplier like AppliancePartsDealer.com, or contact a professional to get the right parts for your specific GE Profile double oven model, such as the GE PT7050EH1ES or GE PT7550SF1SS. - Reconnect and Test 🔄
Once the relay boards have been replaced, carefully reconnect all the wires according to the picture you took earlier. Reattach the metal bracket and secure it with the screws. Reconnect the control panel and reassemble everything. - Power the Oven On 🔋
After reassembling, plug the oven back in and power it on. Check to see if the F34 or F35 error code has cleared, and test the oven to ensure it’s functioning properly.
When to Call for Professional Help with GE Profile 👨🔧
If you’re unsure about performing this repair on your own, or if the F34 or F35 error persists despite following these steps, it might be time to call in a professional. At Atlanta City Appliance Repair, we specialize in high-end appliance repair in Atlanta and can help you get your GE Profile Combo Unit Double Oven back in top shape.
We provide expert repair services for luxury kitchen appliances and are always here to assist with any issues you might have. If you’re in Buckhead, Roswell, Alpharetta, or anywhere in the Atlanta metro area, give us a call today at (404) 903-1453 or visit our website at https://atlantaappliancesrepair.net/ to schedule a service.
Prevent Future Power Surge Issues ⚡
To avoid the F34 or F35 errors in the future, consider installing a surge protector for your oven. Power surges can cause significant damage to sensitive electrical components, so using a surge protector can help extend the lifespan of your oven.
By following these steps, you can tackle the F34 or F35 error codes on your GE Profile double oven and avoid unnecessary repair costs. However, if you’d rather leave it to the pros, Atlanta City Appliance Repair is here to help! 🌟
